Piston Ölçüleri(Piston Dimensions)
A : 75.000
B- : 17.200
BØ : 94.000
C1 : 1.500
D : 113.000
E : 10.000
Pim : 58 x 88
Piston Özellikleri(Piston Features)
Soğutma Kanallı
(Cooling Gallery)
Gözarası Konik
(Conical Eye Gap)
Piston Parça No
(Piston Part No)
87-440600-02
87-75546-STD
Monosteel Çelik Piston
(Steel Piston)
Segman Seti(Ring Set)
06-440600-20-STD
| 3.500 |  | GDC | ST |
| 2.500 |  | CKS | KV4 |
| 3.500 |  | CKS | KV1 |
Goetze® LKZ-Ring®
Yağ Segmanı Matkap Delik
(Oil Ring Drill Hole)
Silindir Gömleği
(Liner)
15-610060-00-WH
B : 141.970
L : 256.000
D : 159.000
C : 7.000
R : 8.900
KURUM GİDERME
RİNGLİ VE O-RİNGLİ
(With Scraper Rings
And O-ring)
24-35053-00/0
1x 130*134*4.6 FKM 75
1x 146*153*3,9 FKM 75
Silindir Kit(Assembly Set)
89-440600-02-STD
89-75546-STD
Piston-Blok Montaj Yüksekliği(Piston – Block Assembly Height)
-0,2090
+0,2315
Ana Yatak(Main Bearing)
72-5021 STD
Kol Yatak(Connecting Rod Bearing)
71-5022 STD
8744060000, A4710301417, 4710301517, 4710301617, 4710302017, 4710302217, 4710302917, 4710303117, 4710370701, 4710372201, 4710372401, 001PI00191000
